Senzor de presiune  PREMASGARD  SHD-692-918 Afisare la marime maxima

Senzor de presiune PREMASGARD SHD-692-918

         VA RUGAM SA NE CONTACTATI

      PENTRU OFERTE PERSONALIZATE!

                        tehnic@acsinstal.com

Detalii

SHD-692-918

Numai online

513,24€


Voltage supply 24 V AC (+15 % ⁄ - 10 %)
18 - 33 V DC
Response time < 5 ms
Output signal 0 - 10 V, 3-wire connection
Measuring range 0... 4 bar
Measuring principle ceramic measuring cell
Media temperature –15...+80 °C
Pressure connection screw pipe connection for 6 mm pipe
(G ⅛ " - 27 NPT internal thread)
Type of pressure differential pressure
Class 0.5 %
Total error < 1.3 %
Max. One-Side Overload 12 bar
System pressure max. 25 bar (P1 + P2)
Measuring range pressure 0...4bar
Bursting pressure 1.5 x system pressure
Medium liquid or gaseous
Insulating resistance ≥ 100 MΩ,
at +20 °C (500V DC)
Electrical connection 0.25 - 1.5 mm², DIN EN 175301- 803 - A
Enclosure stainless steel 1.4305
Connecting head angle plug connector DIN EN 175301- 803 - A
Installation installation arbitrary
Medium contacting parts INOX 1.4305, ceramics, sealing material EPDM
Protection class III (according to EN 60 730)
Protection type IP 65 (according to EN 60 529) with receptacle mounted
Standards CE conformity,
electromagnetic compatibility according to EN 61326,
according to EMC Directive 2014 ⁄ 30 ⁄ EU
Optional Display module, additional height: approx. 50 mm,
for displaying the differential pressure


Item No. 1301-4121-0540-000
EAN 4 251325 612461

Termen livrare : 10 zile lucratoare
