Senzor de presiune  PREMASGARD  SHD-SD Afisare la marime maxima

Senzor de presiune PREMASGARD SHD-SD

         VA RUGAM SA NE CONTACTATI

      PENTRU OFERTE PERSONALIZATE!

                        tehnic@acsinstal.com

Detalii

SHD-SD

Numai online

109,52€

Voltage supply 24 V AC ⁄ DC for output 0 -10 V
7 - 33 V DC for output 4 ... 20 mA
Response time 2 ms (1 ms typical)
Load changes < 100 Hz
Characteristic line ± 0,3 %
Output signal 4... 20 mA, 2-wire, (working resistance < (UB (V) -7 V) ⁄ 0,02 A ;
RL depending on working resistance
Measuring range 0...16 bar
Measuring principle ceramic measuring cell
Media temperature –15...+ 125 °C
Pressure connection G ½ " sealing at the back, and manometer (combined)
with profile gasket FPM, special WW G ¼ " DIN 3852
Type of pressure relative
Overload range/ Bursting pressure < 4 bar: 3 x FS
> 4 bar: 2.5 x FS
Electrical connection plug connector DIN EN 175301-803-A
Enclosure stainless steel 1.4305
Connecting head plastic, approx. 98 x 50 x 34 mm
Installation directly on pressure line
Medium contacting parts stainless steel type 1.4305, AISI 303;
measuring element ceramic Al203 (96%);
sealing material FPM (Viton)
Protection class III (according to EN 60 730)
Protection type IP 65 (according to EN 60 529)
Standards CE conformity,
electromagnetic compatibility according to EN 61326,
according to EMC Directive 2014 ⁄ 30 ⁄ EU
Optional Display module, additional height: approx. 50 mm,
for displaying the differential pressure

LA COMENZILE CU VALOARE MAI MICA DE 150 EUR FARA TVA , SE PERCEPE O TAXA LOGISTICA DE 35 EURO/ COMANDA

Termen livrare : 10 zile lucratoare

Item No. 1301-2122-0570-000
EAN 4 251325 612416
