Senzor de presiune  PREMASGARD  SHD-400 Afisare la marime maxima

Senzor de presiune PREMASGARD SHD 400 U VA 2 BAR

         VA RUGAM SA NE CONTACTATI

      PENTRU OFERTE PERSONALIZATE!

                        tehnic@acsinstal.com

Detalii

SHD 400 U VA 2 BAR

Numai online

311,10€

Voltage supply 24 V AC ⁄ DC (± 20 %)
Permissible working resistance (at nominal voltage) R= 2 kΩ for U
One-sided max. pressure (+) 10 bar
One-sided max. pressure (-) 21 bar
Static operating pressure max. 21 bar
Nominalpressure 16 bar
Response time < 5 ms
Characteristic line < 1 % of final value (at +25 °C)
Output signal 0 - 10 V
Measuring range 0... 2 bar
Media temperature – 20...+80 °C (non-freezing media)
Pressure connection G ⅛ " internal thread
(optional connection types upon request)
Type of pressure differential pressure, above- or below atmospheric pressure
Electrical connection plug connector DIN EN 175301-803-A
Enclosure stainless steel VA 1.4305
Connecting head angle plug connector DIN EN 175301- 803 - A
Installation by 2x M4 screw or
fixing plate for wall mounting
(installation arbitrary)
Medium contacting parts ceramic, stainless steel VA 1.4305, brass, fluorinated rubber
Protection class III (according to EN 60 730)
Protection type IP 65 (according to EN 60 529)
Standards CE conformity,
electromagnetic compatibility according to EN 61326,
according to EMC Directive 2014 ⁄ 30 ⁄ EU

Item No. 1301-4131-0850-139
EAN 4 251325 612508

Termen livrare : 10 zile lucratoare
